Interior Gateway Protocol Definition
An Interior Gateway Protocol (IGP) is a routing protocol that routers use to share information and choose the best path for data within a single network managed by one organization. It enables routers in the same system to communicate, update routes, and keep traffic moving efficiently and reliably.
How Interior Gateway Protocols Work
IGPs work by having routers regularly exchange routing updates with each other to maintain an accurate view of the network. Each router shares the networks it can reach along with a protocol-specific cost (metric), such as hop count in RIP or cost based on bandwidth in OSPF. Routers compare this information, select the most efficient path, update their routing tables, and forward data accordingly. If network conditions change, such as a link failure or a better route becoming available, routers quickly adjust to keep data flowing without interruption.
Types of Interior Gateway Protocols
- Distance Vector Protocols: Choose routes based on a distance metric (such as hop count in RIP). Routers share routing information with neighbors (often full routing tables in simpler protocols like RIP). Simple but slower to adapt.
- Link-State Protocols: Builds a full map of the network and calculates the best path. Faster and more efficient, especially in large networks.
Common IGP Examples
- Routing Information Protocol (RIP): A distance vector protocol that selects routes based on hop count. One of the oldest IGPs, it has a maximum of 15 hops and slower convergence, making it less suitable for large modern networks.
- Open Shortest Path First (OSPF): A link-state protocol that calculates the best path using a cost metric based on bandwidth. Scalable and widely used, it adapts quickly to changes in larger networks.
- Enhanced Interior Gateway Routing Protocol (EIGRP): An advanced distance-vector protocol that uses a composite metric based on bandwidth and delay. Originally Cisco-proprietary, EIGRP was later published as an informational RFC (RFC 7868) but is still primarily used in Cisco-based networks.
- Intermediate System to Intermediate System (IS-IS): A link-state protocol known for fast convergence and strong scalability. It is widely used in large-scale carrier networks and hyperscaler data centers and is often deployed alongside modern technologies such as Segment Routing (SR-MPLS or SRv6).
Interior Gateway Protocol vs Exterior Gateway Protocol
An Interior Gateway Protocol (IGP) is a routing protocol that routers use to share information and choose the best path for data within a single network. On the other hand, an Exterior Gateway Protocol (EGP) allows routers to exchange information and route data between different networks.
Read More
FAQ
Interior Gateway Protocols aren’t fully secure by default. They rely on trust between routers within the same network, which can make them vulnerable to route injection and other routing manipulation attacks if an attacker gains access to a router or network segment. However, many IGPs support security features like authentication to verify routing updates and reduce these risks.
No, Interior Gateway Protocols don’t work over the internet. They operate within a single network or autonomous system. The internet uses exterior routing protocols to exchange data between different networks.
Routers use IGPs to choose the best path by comparing available routes using protocol-specific metrics such as hop count (RIP) or cost based on bandwidth (OSPF). Each router receives routing updates from its neighbors, evaluates the possible paths, and selects the one with the lowest cost. It then updates its routing table and forwards data along that path.
